The MSD6750 is a professional Petrographic Analysis Microscope designed for geology, mineral observation, and rock analysis applications. Its transmitted and reflected light system provides flexible polarized imaging for different sample materials and laboratory research environments.
Designed with stable optical components and clear polarized imaging performance, the microscope supports accurate observation of crystalline structures, minerals, and petrographic samples. The trinocular optical system improves efficiency in laboratory analysis and educational applications.
Suitable for universities, geological laboratories, and industrial material inspection, the Petrographic Analysis Microscope delivers reliable imaging performance for mineral studies, petrographic research, and advanced laboratory observation.
| Attribute | Value | Attribute | Value |
|---|---|---|---|
| type | Trinocular Microscope | illumination | LED |
| Focus Type | Manual Focus | Dioptric Adjustment | ±5d |
| camera resolution | Other | External Display Support | Yes |
| IP Rating | IP54 | warranty | 1 Year |
| customized support | OEM, ODM | place of origin | Guangdong, China |
| model number | MSD6750 | brand name | Murzider |
| Service | OEM,ODM | Brand | Murzider |
| Model | MSD6750 | Total magnification | 50X-600X |
| Flat field eyepiece | Wide-field eyepiece WF10X/18mm | Split eyepiece | WF10X/18mm, 0.10mm/div |
| Observation Head | Trinocular | Converter | Four holes (outward ball inward positioning) |
| Abbe condenser | N.A. 1.25 Adjustable up and down | Warranty period | 1 year |
| Attribute | Value | Attribute | Value |
|---|---|---|---|
| Selling Units | Single item | Single package size | 44X32X57 cm |
| Single gross weight | 13.000 kg |
